| Type | Digital Input |
| Signal specification | 24 V d.c. |
| Article number | 3BSE008508R1 |
| Number of channels | 16 |
| Signal type | Current sinking |
| HART | No |
| SOE | No |
| Redundancy | No |
| High integrity | No |
| Intrinsic safety | No |
| Mechanics | S800 |
| Thông số kỹ thuật: | |
| Input voltage range, “0” | -30..+5 V |
| Input voltage range, “1” | 15..30 V |
| Input impedance | 3.5 kΩ |
| Isolation | Groupwise isolated from ground, 2 groups with 8 channels |
| Filter times (digital, selectable) | 2, 4, 8, 16 ms |
| Current limiting | Sensor power can be current limited by the MTU |
| Maximum field cable length | 600 meters (656 yards) |
| Rated insulation voltage | 50 V |
| Dielectric test voltage | 500 V a.c. |
| Power dissipation | Typ. 1.8 W |
| Current consumption +5 V Modulebus | 50 mA |
| Current consumption +24 V Modulebus | 0 |
| Current consumption +24 V external | 0 |
