| General technical data | ||
| consumed active power / rated value / maximum | 180 mW | |
| surge voltage / rated value | 2 kV | |
| Measuring inputs | ||
| operating range of measuring inputs / for current measurement | ±10 mA | |
| Inputs / Outputs | ||
| number of analog inputs | 4 | |
| design of analog input / configurable | Yes | |
| A/D resolution / at the analog input | 16 bit | |
| input variable / at the analog input / current signal | Yes | |
| input variable / at the analog input / voltage | Yes | |
| output quantity / at analog output / current signal | No | |
| output quantity / at analog output / voltage | No | |
| Mechanical Design | ||
| width | 30 mm | |
| height | 132 mm | |
| depth | 124 mm | |
| fastening method / DIN-rail mounting | Yes | |
| fastening method / wall mounting | No | |
| fastening method / rack mounting | No | |
| type of electrical connection | screw connection | |
| connectable conductor cross-section | 0.33 ... 2.5 mm² | |
| material / of the enclosure | plastic | |
| product feature / plug-in terminal blocks | Yes | |
| product function / with function display | Yes | |
| product function / status display | No | |
| Degree of protection / protection class | ||
| operating resource protection class | II | |
| degree of pollution | 2 | |
| protection class IP / on the front | IP40 | |
| Environmental conditions | ||
| ambient temperature / during operation | -40 ... +70 °C | |
| ambient temperature / during storage | -30 ... +85 °C | |
| relative humidity | 5 ... 95 % | |
| mounting height in relation to mean sea level / maximum | 3 000 m | |
| air pressure / maximum | 106 kPa | |
| Approval certification | ||
| certificate of suitability / CE marking | Yes | |
